Automatic Spice/Beef Jerky/Tobacco Packaging Machine Price for Sale
This machine is widely applied for food,phamacy eutical,and chemical products in mesh size range from 120 to 400,such as milk powder,soya powder,cosmetic powder,slimming tea,medical powder.etc.
1) Be able to weight, bag-making, filling, sealing, cutting,lot number automatically.
2) It has color control system which can get the complete trade mark design
(photoelectricity control system).
3) The machine fix stepper motor controller,its advantage is precise,needless to adjust other parts
4) Intelligent temperature control by temperature controller to make heat balance better.use bilingual display screen control system and stainless steel cabinet
5) Fine packaging performance ,low noise ,clear sealing texture and strong sealing performance
6) With safe plastic box on rotating blade to avoid hurting operator's hands
7) Need to change new temperature controller,blade& pressing mode only after 3 years continuous operation,2 shifts a day and other parts is still good and safe freely)
8)With printer (to be able to code the date and batch number) and rotating blade(be able to adjust the length of bag and shape of bag notch edge packing.
Operation and adjustment
1. The requirements of operating this machine: Put through the elec. Power and cleaned compressed air, put the shell of the machine safely to the ground, set up the total work pressure as 0.6 Mpa,
And pour into lubrication positions and cylinder lubrication( we suggest that cylinder pour into pure white
2. Put the packing materials in the film scroll and fix the shelter (the printed-page outward or the compound page inward). Penetrate the packing materials according to picture of the film's locus.
3. Press the electrical switch in the electricity operation board, the indicator light is turned on, then the machine begin in the state of awaiting an opportunity. Version indicator showed as follows:
4. According to the packing materials pass the temperature controller of the board to set up trial sealing temperature.
The temperature set up method of the temperature controller: Press key in the temperature controller to set up, made the PL window indicates words "50", SV window unit twinkle, then press keyor
5. Examine the situation of the packing materials, to see whether the packing materials is in the obverse side of the finished-form machine, if not, then you need to adjust from left, right, above and below; Or adjust the axle position of the packing materials in the film scroll, made the two-wheel pull the packing materials easily.
|the maximum bag size(L*W)||150*120mm||200*160mm||260*190mm|
|packing maximum speed||2400bags/h||1800bags/h||1200bags/h|
